Stainless Steel Single Shaft Paddle Mixer With Ribbon Used for Slurry Mixture
official website:www.1985shengli.com
Paddle blender is widely applied in chemical, biological,rubber and PVC, PP, PE, ABS, plastic area.
It can mix granular material, plastic material in battery, construction, environmental, mineral and agricultural line blending process,especially for big size material or fragile material
single shaft mixers,blending mechinery, mixer for diet powder,powder mixing equipment manufacturer in China.
Single shaft mixers,blending mechinery, mixer for diet powder,powder mixing equipment manufacturer in China.
Features
| 1. Scope of Application |
| In the U-shaped container, there are positive and negative paddles. Special proportion of the paddles agitator can be rectified with the kind of material, quantity and the proportion of body. This mixer has good effect on mixing viscosity or cohesion powder. |
| 2. Characteristic |
| In the U-shaped container, there are positive and negative paddles. Special proportion of the paddles agitator can be rectified with the kind of material, quantity and the proportion of body. This mixer has good effect on mixing viscosity or cohesion powder. |
| 3.Working Principle |
| a, The horizontal axes make the materials move up and down.
b, The outer paddle gathering the material from sides to center and the inner paddle pushing the material from center to sides.
c, Every screw makes the materials do axial and radial movement, the materials do relative cyclical movement so to gain the intensive mixings ends. |
Specification
| Type(m3) | Power(kw) | Rotate Speed(R/min) | (kg)(m3)/Batch | Dimension(mm) | Weight |
| FKM-0.3 | 3 | 41 | <240 | 2300×680×1060 | 750 |
| FKM-0.5 | 5.5 | 41 | <400 | 2900×780×1240 | 1000 |
| FKM-1 | 11 | 33 | <800 | 3200×1000×1400 | 1800 |
| FKM2 | 15 | 33 | <1600 | 3860×1200×1650 | 2200 |
| FKM-3 | 18.5 | 33 | <2400 | 4320×1300×1900 | 3200 |
| FKM-4 | 22 | 28 | <3200 | 4600×1400×2000 | 4000 |
| FKM-5 | 37 | 28 | <4000 | 4850×1500×2020 | 4650 |
| FKM-6 | 37 | 22 | <4800 | 5400×1560×2200 | 6280 |
| FKM8 | 45 | 22 | <6400 | 5100×1720×2420 | 8500 |
| FKM-10 | 55 | 19 | <8000 | 5610×1750×2360 | 9300 |
| FKM-15 | 90 | 17 | <12000 | 5820×2000×2900 | 11000 |
| FKM-20 | 110 | 11 | <16000 | 6060×2630×3160 | 13500 |
Seal
The mixing result and the clean after-mixing environment depend on the sealing property. Our company provides various sealing devices according to difference of materials. The normal sealing structure is stuff seal and also called TEFLON seal. After using for a period, user(s) should fasten and enhance it. However, the dynamic seal has a long-time sealing effect and is especially fit for the powder, liquid.
Feeding inlet on the body cover
Two types:
a, used in the whole mixing/ blending process: in order to connect the feeding device, we design the connecting mouth.
b, used in the manual feeding: in order to operate and clean inside of the body, we design feeding inlet(s) or door(s).
